KITZ DJ Series Butterfly Valves size inch 2to24 DN50 to DN600
Flanged Class 150..... ASME 150 psi 200..... ASME 200 psi PN16... EN PN16 PN25... EN PN25 10....... JIS 10K 16....... JIS 16K
Model DJ........ Ductile iron DJ series *Cast iron for JIS10K, Size 350-600 FDDJ.... Ductile iron for JIS10K, Size 350-600 (Option)
Disc material None.... Ductile iron (Ni-plated) U......... 304 stainless steel M........ 316 stainless steel A......... Aluminum bronze
Seat material None.... NBR (Buna-N) E.......... EPDM
